If you are interested in ordering this device, please contact us for further information.

The Thuraya IP NEO is a next-generation satellite terminal engineered for professionals who cannot afford downtime. Delivering broadband speeds up to 1024 kbps, the IP NEO enables seamless VoIP calling, video conferencing, live data transfer, and IoT/M2M connectivity in the world’s most remote locations.

At just 2.2 kg, this lightweight device is easy to carry yet powerful enough for mission-critical operations. Its IP55-rated magnesium casing and secure connectors make it tough enough for field use, while the built-in Wi-Fi hotspot ensures quick access for multiple devices. Setup is fast and simple, going from backpack to live connection in seconds.

From defense and homeland security teams to energy providers, emergency responders, and field journalists, the Thuraya IP NEO is trusted to deliver reliable communications when nothing else can. Whether you’re managing a disaster zone, transmitting live video, or monitoring remote assets, the IP NEO keeps you connected, informed, and operational.

Key Advantages:

Broadband speeds up to 1024 kbps via Thuraya 4-NGS satellite
Compact and battery-powered (only 2.2 kg)
Built-in Wi-Fi hotspot and smartphone app control
Rugged IP55-certified housing for tough environments
Rapid deployment with simple, intuitive setup
Supports ISR, command and control, IoT/M2M, telemedicine, video transmission, and more

Specification

Category	Specification
Device
Dimensions (H × W × D)	225 × 225 × 61.5 mm
Weight (incl. battery)	2.2 kg
Data & Voice
Data (Thuraya 4-NGS)	Up to 1024 kbps (Rx/Tx) at > 5° elevation
Data (Thuraya 2/3)	Up to 444 kbps (Rx/Tx) at > 5° elevation
Voice (Thuraya 4-NGS)	Standard VoIP, Embedded SIP Server
RF & GNSS
Frequencies (Tx)	1626.5–1660.5 MHz
Frequencies (Rx)	1525.0–1559.0 MHz
GNSS	GPS, Galileo, Beidou, Glonass
Languages & Approvals
Languages	ENG, AR, FR, POR, ES, RU, JP, CN
Approvals	CE, RED, RoHS, WEEE, FCC, UL, RCM; Thuraya Type Approval
Power
DC input range	12–24 VDC (max. 10.8–33.6 VDC)
PoE input	PoE (802.3bt Type 3 Class 6 via RJ45)
PoE output	PoE (802.3at Type 1 Class 2 via RJ45)
Power consumption	Standby/Transmit: 4.5 W / 22 W (typical); During charging: 75 W (max.)
AC/DC power supply (input)	100–240 VAC, 47–63 Hz, 64 W
AC/DC power supply (output)	19 VDC
Battery type	Lithium-ion (rechargeable)
Battery (nom. voltage / capacity)	10.8 V / 6.9 Ah
Battery run time (standby)	Up to 38 hours*
Battery run time (receive)	Up to 4 hours @ 1024 kbps*
Battery run time (transmit)	Up to 2 hours @ 1024 kbps*
Recharge time	< 3 hours (0–100%)
Charge temperature	0°C to 45°C
Environmental
Operating temperature (ambient)	−21°C to +55°C
Storage temperature	−21°C to +50°C
Ingress protection	IP55 compliant
Interfaces
WLAN access point	802.11 b/g/n/ac
Ethernet	2 × RJ45: 1 × PoE input (external power), 1 × PoE output (IP Handset)
User interface	2 × LED (Status, WLAN), Power Button, Reset Button, Web Interface
Features
Companion app	Thuraya Connect App (Android / iOS)
Router & management	Webserver, NAT Router, Admin control (password protected), DHCP, Network Management, Remote Management, PPPoE
Package Contents
In the box	IP NEO C Terminal with embedded Lithium-Ion Battery; AC/DC Power Supply; Euro Power Cord; EU to UK Converter; Quick Start Guide; Ethernet Cable

On Thuraya 4-NGS.

Downloads

Download Thuraya IP NEO User Manual
