The Iridium 9603 Developer's Kit is the smallest form factor of any commercial satellite transceiver currently available, and allows users to develop their own tracking device that runs off the Iridium satellite network.
| Dimensions | 3.2 x 3 x 0.8 cm |
| Weight | 11.4 g |
| Operating temperature range | -30°c to +70°c |
| Operating humidity range | 75% RH |
| Storage temperature range | -40°c to +85°c |
| Frequency range | 1616 MHz to 1626.5 MHz |
| Duplexing Method | TDD (Time Domain Duplex) |
| Input/Output Impedance | 50 |
| Multiplexing Method | TDMA/FDMA |
| DC Power Input | |
| Supply input voltage range | 5.0V +/- .2V DC |
| Idle current (average) | 45mA |
| Idle current (peak) | 195mA |
| Transmit current (peak) | 1.5A |
| Transmit current (average) | 190 mA |
| Receive current (peak) | 195mA |
| Receive current (average) | 45mA |
| SBD Message transfer - average current | 190mA |
| SBD Message transfer - average power | 1.0W |
